- Filter the product selection by selecting the features that interest you. Select or deselect all to view the complete list.
SGV car door
Ideal for new installations and modernizations
SGV car door
SGV is a door equipment for MID and HEAVY duty new installation and modernization.
Discover
Nettuno kooideur
Met rechte onderaandrijving
Nettuno kooideur
Nettuno-kooideur is de perfecte oplossing wanneer het niet mogelijk is om de aandrijving boven het cabinedak te plaatsen.
Discover
Luna kooideur
Riem aangedreven ronde uitvoering
Luna kooideur
De LUNA-kooideur met SUPRA-aandrijving is de ideale oplossing voor prestigieuze panoramische liften in alle soorten en maten.
Discover.png)
AMD 2 kooideur mechanisme
Mechanisme voor kooideur
AMD 2 kooideur mechanisme
AMD is een kooideurmechanisme dat gebruikt kan worden in eender welke toepassing: van woontorens tot drukbezochte kantoorgebouwen en hotels.
Discover
ECO+ MIDI+ SUPRA
Deuraandrijvingen met hoge energie-efficiëntie
ECO+ MIDI+ SUPRA
Discover
Sematic 2000 C-MOD Kooideur specificaties
De flexibele deur
Sematic 2000 C-MOD Kooideur specificaties
Verbeterde prestaties, veiligheid en comfort voor passagiers in bestaande liftsystemen.
Moet u uw bestaande liftdeuren upgraden om te voldoen aan de EN81-80 vereisten? Zoekt u een compacte, flexibele oplossing voor modernisering zonder concessies te doen aan prestaties, kwaliteit, kosten en veiligheid? Sematic 2000 C-MOD is het antwoord.
Sematic 2000 B-HR
De hoge liftdeur
Sematic 2000 B-HR
Sematic 2000 B-HR is de ideale oplossing voor personenvervoer in hoogbouw.
DiscoverProduct Comparison Tool
| AUGUSTA EVO | HYDRA PLUS ECO+ |
HYDRA PLUS MIDI+ |
HYDRA PLUS SUPRA |
HYDRA PLUS UD300 ECO+ |
HYDRA PLUS UD300 MIDI+ |
PEGASUS PLUS MIDI |
PEGASUS PLUS SUPRA |
HYDRA 3000 PLUS ECO+ |
HYDRA 3000 PLUS MIDI+ |
ECO BUS | FINELINE | NETTUNO MIDI+ |
NETTUNO SUPRA |
LUNA PLUS | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Type | ECO+ | ECO+ | MIDI+ | SUPRA | ECO+ | MIDI+ | MIDI | SUPRA | ECO+ | MIDI+ | ECO+ | ECO+ | MIDI+ | SUPRA | SUPRA |
| Light curtain | Fixed | Fixed and dynamic | Fixed and dynamic | Fixed and dynamic | Fixed and dynamic | Fixed and dynamic | Fixed and dynamic | Fixed and dynamic | Fixed and dynamic | Fixed and dynamic | Fixed and dynamic | Fixed and dynamic | Fixed and dynamic | Fixed and dynamic | Fixed and dynamic |
| IP54 | - | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional |
| Drives | 3-phase PMSM Vector control |
3-phase PMSM Vector control |
3-phase PMSM Vector control |
3-phase PMSM Vector control |
3-phase PMSM Vector control |
3-phase PMSM Vector control |
3-phase PMSM Vector control |
3-phase PMSM Vector control |
3-phase PMSM Vector control |
3-phase PMSM Vector control |
3-phase PMSM Vector control |
3-phase PMSM Vector control |
3-phase PMSM Vector control |
3-phase PMSM Vector control |
3-phase PMSM Vector control |
| Power Supply | Univ. (127V, 2A) +/- 20% (230V,1A) +/- 20% 50/60 Hz |
Univ. (127V, 2A) +/- 20% (230V,1A) +/- 20% 50/60 Hz |
Univ. (127V, 6A) +/- 20% (230V,4A) +/- 20% 50/60 Hz |
Univ. (127V, 6A) +/- 20% (230V,4A) +/- 20% 50/60 Hz |
Univ. (127V, 2A) +/- 20% (230V,1A) +/- 20% 50/60 Hz |
Univ. (127V, 6A) +/- 20% (230V,4A) +/- 20% 50/60 Hz |
Univ. (127V, 6A) +/- 20% (230V,4A) +/- 20% 50/60 Hz |
Univ. (127V, 2A) +/- 20% (230V,4A) +/- 20% 50/60 Hz |
Univ. (127V, 2A) +/- 20% (230V,1A) +/- 20% 50/60 Hz |
Univ. (127V, 6A) +/- 20% (230V,4A) +/- 20% 50/60 Hz |
Univ. (127V, 6A) +/- 20% (230V,1A) +/- 20% 50/60 Hz |
Univ. (127V, 2A) +/- 20% (230V,1A) +/- 20% 50/60 Hz |
Univ. (127V, 6A) +/- 20% (230V,1A) +/- 20% 50/60 Hz |
Univ. (127V, 6A) +/- 20% (230V,1A) +/- 20% 50/60 Hz |
Univ. (127V, 6A) +/- 20% (230V,1A) +/- 20% 50/60 Hz |
| Class Protection | IP20 | IP20 | IP20 | IP20 | IP20 | IP20 | IP20 (IP54 on request) | IP20 (IP54 on request) | IP20 | IP20 (IP54 on request) | IP20 | IP20 | IP20 (IP54 on request) | IP20 (IP54 on request) | IP20 (IP54 on request) |
| Maximum movable masses (car and landing door panels) |
130 kg | 130 kg | 300 kg | 700 kg | 130 kg | 300 kg | 300 kg | 700 kg | 130 kg | 300 kg | 130 kg | Available | 300 kg | 700 kg | 700 kg |
| Car Door Lock (Optional) |
Available | Available | Available | Available | Available | Available | Available | Available | Available | Available | Available | Available | Available | Available | Available |
| Self-Learning | Available | Available | Available | Available | Available | Available | Available | Available | Available | Available | Available | Available | |||
| Protective device - Power Supply | 24V DC +10% 150 mA |
24V DC +10% 150 mA |
24V DC +10% 150 mA |
24V DC +10% 150 mA |
24V DC +10% 150 mA |
24V DC +10% 150 mA |
24V DC +10% 150 mA |
24V DC +10% 150 mA |
24V DC +10% 150 mA |
24V DC +10% 150 mA |
24V DC +10% 150 mA |
24V DC +10% 150 mA |
24V DC +10% 150 mA |
24V DC +10% 150 mA |
24V DC +10% 150 mA |
| Emergency battery drive | 18-26 VDC max 5A |
18-26 VDC max 5A |
18-26 VDC max 25A |
18-26 VDC max 20A |
18-26 VDC max 5A |
18-26 VDC max 25A |
18-26 VDC max 15A |
18-26 VDC max 20A |
18-26 VDC max 5A |
18-26 VDC max 25A |
18-26 VDC max 5A |
18-26 VDC max 5A |
18-26 VDC max 25A |
18-26 VDC max 20A |
18-26 VDC max 20A |
